Shared variable control
Ada has built-in support for handling both volatile and atomic data. Let's start by discussing volatile objects.
In the Ada Reference Manual
Volatile
A volatile object can be described as an object in memory whose value may change between two consecutive memory accesses of a process A — even if process A itself hasn't changed the value. This situation may arise when an object in memory is being shared by multiple threads. For example, a thread B may modify the value of that object between two read accesses of a thread A. Another typical example is the one of memory-mapped I/O, where the hardware might be constantly changing the value of an object in memory.
Because the value of a volatile object may be constantly changing, a compiler cannot generate code to store the value of that object in a register and then use the value from the register in subsequent operations. Storing into a register is avoided because, if the value is stored there, it would be outdated if another process had changed the volatile object in the meantime. Instead, the compiler generates code in such a way that the process must read the value of the volatile object from memory for each access.
Let's look at a simple example:
with Ada.Text_IO; use Ada.Text_IO;
procedure Show_Volatile_Object is
Val : Long_Float with Volatile;
begin
Val := 0.0;
for I in 0 .. 999 loop
Val := Val + 2.0 * Long_Float (I);
end loop;
Put_Line ("Val: " & Long_Float'Image (Val));
end Show_Volatile_Object;
In this example, Val has the Volatile aspect, which makes the
object volatile. We can also use the Volatile aspect in type
declarations. For example:
package Shared_Var_Types is
type Volatile_Long_Float is new
Long_Float with Volatile;
end Shared_Var_Types;
with Ada.Text_IO; use Ada.Text_IO;
with Shared_Var_Types; use Shared_Var_Types;
procedure Show_Volatile_Type is
Val : Volatile_Long_Float;
begin
Val := 0.0;
for I in 0 .. 999 loop
Val := Val + 2.0 * Volatile_Long_Float (I);
end loop;
Put_Line ("Val: "
& Volatile_Long_Float'Image (Val));
end Show_Volatile_Type;
Here, we're declaring a new type Volatile_Long_Float in the
Shared_Var_Types package. This type is based on the Long_Float
type and uses the Volatile aspect. Any object of this type is
automatically volatile.
In addition to that, we can declare components of an array to be volatile. In
this case, we can use the Volatile_Components aspect in the array
declaration. For example:
with Ada.Text_IO; use Ada.Text_IO;
procedure Show_Volatile_Array_Components is
Arr : array (1 .. 2) of Long_Float
with Volatile_Components;
begin
Arr := (others => 0.0);
for I in 0 .. 999 loop
Arr (1) := Arr (1) + 2.0 * Long_Float (I);
Arr (2) := Arr (2) + 10.0 * Long_Float (I);
end loop;
Put_Line ("Arr (1): "
& Long_Float'Image (Arr (1)));
Put_Line ("Arr (2): "
& Long_Float'Image (Arr (2)));
end Show_Volatile_Array_Components;
Note that it's possible to use the Volatile aspect for the array
declaration as well:
package Shared_Var_Types is
private
Arr : array (1 .. 2) of Long_Float
with Volatile;
end Shared_Var_Types;
Note that, if the Volatile aspect is specified for an object, then the
Volatile_Components aspect is also specified automatically — if it
makes sense in the context, of course. In the example above, even though
Volatile_Components isn't specified in the declaration of the Arr
array , it's automatically set as well.
Independent
When you write code to access a single object in memory, you might actually be
accessing multiple objects at once. For example, when you declare types that
make use of representation clauses — as we've seen in previous sections
—, you might be accessing multiple objects that are grouped together in
a single storage unit. For example, if you have components A and
B stored in the same storage unit, you cannot update A without
actually writing (the same value) to B. Those objects aren't
independently addressable because, in order to access one of them, we have to
actually address multiple objects at once.
When an object is independently addressable, we call it an independent object. In this case, we make sure that, when accessing that object, we won't be simultaneously accessing another object. As a consequence, this feature limits the way objects can be represented in memory, as we'll see next.
To indicate that an object is independent, we use the Independent
aspect:
package Shared_Var_Types is
I : Integer with Independent;
end Shared_Var_Types;
Similarly, we can use this aspect when declaring types:
package Shared_Var_Types is
type Independent_Boolean is new Boolean
with Independent;
type Flags is record
F1 : Independent_Boolean;
F2 : Independent_Boolean;
end record;
end Shared_Var_Types;
In this example, we're declaring the Independent_Boolean type and using
it in the declaration of the Flag record type. Let's now derive the
Flags type and use a representation clause for the derived type:
package Shared_Var_Types.Representation is
type Rep_Flags is new Flags;
for Rep_Flags use record
F1 at 0 range 0 .. 0;
F2 at 0 range 1 .. 1;
-- ^ ERROR: start position of
-- F2 is wrong!
-- ^ ERROR: F1 and F2 share the
-- same storage unit!
end record;
end Shared_Var_Types.Representation;
As you can see when trying to compile this example, the representation clause
that we used for Rep_Flags isn't following these limitations:
The size of each independent component must be a multiple of a storage unit.
The start position of each independent component must be a multiple of a storage unit.
For example, for architectures that have a storage unit of one byte — such as standard desktop computers —, this means that the size and the position of independent components must be a multiple of a byte. Let's correct the issues in the code above by:
setting the size of each independent component to correspond to
Storage_Unit— using a range between 0 andStorage_Unit - 1—, andsetting the start position to zero.
This is the corrected version:
with System;
package Shared_Var_Types.Representation is
type Rep_Flags is new Flags;
for Rep_Flags use record
F1 at 0 range 0 .. System.Storage_Unit - 1;
F2 at 1 range 0 .. System.Storage_Unit - 1;
end record;
end Shared_Var_Types.Representation;
Note that the representation that we're now using for Rep_Flags is most
likely the representation that the compiler would have chosen for this data
type. We could, however, have added an empty storage unit between F1 and
F2 — by simply writing F2 at 2 ...:
with System;
package Shared_Var_Types.Representation is
type Rep_Flags is new Flags;
for Rep_Flags use record
F1 at 0 range 0 .. System.Storage_Unit - 1;
F2 at 2 range 0 .. System.Storage_Unit - 1;
end record;
end Shared_Var_Types.Representation;
As long as we follow the rules for independent objects, we're still allowed to use representation clauses that don't correspond to the one that the compiler might select.
For arrays, we can use the Independent_Components aspect:
package Shared_Var_Types is
Flags : array (1 .. 8) of Boolean
with Independent_Components;
end Shared_Var_Types;
We've just seen in a previous example that some representation clauses might
not work with objects and types that have the Independent aspect. The
same restrictions apply when we use the Independent_Components aspect.
For example, this aspect prevents that array components are packed when the
Pack aspect is used. Let's discuss the following erroneous code example:
package Shared_Var_Types is
type Flags is
array (Positive range <>) of Boolean
with Independent_Components, Pack;
F : Flags (1 .. 8) with Size => 8;
end Shared_Var_Types;
As expected, this code doesn't compile. Here, we can have either independent
components, or packed components. We cannot have both at the same time because
packed components aren't independently addressable. The compiler warns us that
the Pack aspect won't have any effect on independent components. When we
use the Size aspect in the declaration of F, we confirm this
limitation. If we remove the Size aspect, however, the code is compiled
successfully because the compiler ignores the Pack aspect and allocates
a larger size for F:
package Shared_Var_Types is
type Flags is
array (Positive range <>) of Boolean
with Independent_Components, Pack;
end Shared_Var_Types;
with Ada.Text_IO; use Ada.Text_IO;
with System;
with Shared_Var_Types; use Shared_Var_Types;
procedure Show_Flags_Size is
F : Flags (1 .. 8);
begin
Put_Line ("Flags'Size: "
& F'Size'Image & " bits");
Put_Line ("Flags (1)'Size: "
& F (1)'Size'Image & " bits");
Put_Line ("# storage units: "
& Integer'Image
(F'Size /
System.Storage_Unit));
end Show_Flags_Size;
As you can see in the output of the application, even though we specify the
Pack aspect for the Flags type, the compiler allocates eight
storage units, one per each component of the F array.
Atomic
An atomic object is an object that only accepts atomic reads and updates. The Ada standard specifies that "for an atomic object (including an atomic component), all reads and updates of the object as a whole are indivisible." In this case, the compiler must generate Assembly code in such a way that reads and updates of an atomic object must be done in a single instruction, so that no other instruction could execute on that same object before the read or update completes.
In other contexts
Generally, we can say that operations are said to be atomic when they can be completed without interruptions. This is an important requirement when we're performing operations on objects in memory that are shared between multiple processes.
This definition of atomicity above is used, for example, when implementing databases. However, for this section, we're using the term "atomic" differently. Here, it really means that reads and updates must be performed with a single Assembly instruction.
For example, if we have a 32-bit object composed of four 8-bit bytes, the compiler cannot generate code to read or update the object using four 8-bit store / load instructions, or even two 16-bit store / load instructions. In this case, in order to maintain atomicity, the compiler must generate code using one 32-bit store / load instruction.
Because of this strict definition, we might have objects for which the
Atomic aspect cannot be specified. Lots of machines support integer
types that are larger than the native word-sized integer. For example, a
16-bit machine probably supports both 16-bit and 32-bit integers, but only
16-bit integer objects can be marked as atomic — or, more generally,
only objects that fit into at most 16 bits.
Atomicity may be important, for example, when dealing with shared hardware
registers. In fact, for certain architectures, the hardware may require that
memory-mapped registers are handled atomically. In Ada, we can use the
Atomic aspect to indicate that an object is atomic. This is how we can
use the aspect to declare a shared hardware register:
with System;
package Shared_Var_Types is
private
R : Integer
with Atomic,
Address =>
System'To_Address (16#FFFF00A0#);
end Shared_Var_Types;
Note that the Address aspect allows for assigning a variable to a
specific location in the memory. In this example, we're using this aspect to
specify the address of the memory-mapped register.
Later on, we talk again about the Address aspect and the GNAT-specific System'To_Address attribute.
In addition to atomic objects, we can declare atomic types — similar to what we've seen before for volatile objects. For example:
with System;
package Shared_Var_Types is
type Atomic_Integer is new Integer
with Atomic;
private
R : Atomic_Integer
with Address =>
System'To_Address (16#FFFF00A0#);
end Shared_Var_Types;
In this example, we're declaring the Atomic_Integer type, which is an
atomic type. Objects of this type — such as R in this example
— are automatically atomic.
We can also declare atomic array components:
package Shared_Var_Types is
private
Arr : array (1 .. 2) of Integer
with Atomic_Components;
end Shared_Var_Types;
This example shows the declaration of the Arr array, which has atomic
components — the atomicity of its components is indicated by the
Atomic_Components aspect.
Note that if an object is atomic, it is also volatile and independent. In other words, these type declarations are equivalent:
package Shared_Var_Types is
type Atomic_Integer_1 is new Integer
with Atomic;
type Atomic_Integer_2 is new Integer
with Atomic,
Volatile,
Independent;
end Shared_Var_Types;
A simular rule applies to components of an array. When we use the
Atomic_Components, the following aspects are implied: Volatile,
Volatile_Components and Independent_Components. For example,
these array declarations are equivalent:
package Shared_Var_Types is
Arr_1 : array (1 .. 2) of Integer
with Atomic_Components;
Arr_2 : array (1 .. 2) of Integer
with Atomic_Components,
Volatile,
Volatile_Components,
Independent_Components;
end Shared_Var_Types;
